Vibration Sensor: Acceleration 4-20mA Cabled Version - Extended Temperature Range
Vibration Sensor/Transmitter: Acceleration 4-20mA Output
The VS series of vibration sensors provide measurement of overall vibration levels being generated by all types of rotating machinery in Hazardous Areas, and can be directly connected to PLC, DCS and other industrial controllers.
The VS-A1-HT type are loop powered, 4-20mA output vibration sensors configured with a full scale acceleration output (RMS or Peak) of between 5g to 50g. The housing is manufactured from 316 stainless steel, and it is provided with a fully potted cable suitable for use in -55°C to +90°C environments.
Benefiting from state-of-the-art annular shear design, our VS series sensors provide better frequency response, improved base strain, lower noise, and an insensitivity to cable motion compared to the market competition.
It is available certified for Hazardous Area use including ATEX / IECEx / UL / CSA / TRCU & INMETRO.
- Contact Arrangement
- SPCO / SPDT (Form C)
- Connection Type
- General Industrial
- Temperature Class (T Rating)
- T6/T4 (Can also be used in T5 and T3)
- Operating Temperature
- -20°C to +80°C / -4°F to +176°F
- Environmental Protection
- IP66, 67 / NEMA 4X, 6P
- Output Type
- 5 - 50g (RMS / Peak)
- Vibration Limit (Continuous)
- Shock Limit
- 2500g peak
All of our products are also available as Ordinary Location / General Industrial.
