Proximity Switch - Magnetic
Proximity/Limit Switch for General Industrial Use
For certifications see products
| Magnet Part No. | MA-1S | MA-4S | MA-7S |
|---|---|---|---|
| Sensing Range in mm (") | 12 | 12 | 20 |
| Magnet Datasheets |
|
|
|
Documents to view/download
Proximity/Limit Switch for General Industrial Use
ES-45 Series Magnetic Proximity Switch has a 316 Stainless Steel Cylindrical Housing with volt free contacts. It has a maximum switching current of 830mA. It requires the use of a magnetic target to operate.
Suitable for use in the design of safety functions up to SIL2 or SIL3.
Using the latest production methods and materials this product meets global certification requirements and its robust design makes it suitable for use in arduous and hazardous environments.
Euroswitch products are also available with multi-approvals including combinations of the following global and regional certification standards; ATEX / IECEx Ex d (Ex db); Ex ia; UL & CSA Cl I Div 1 & 2 and Cl2 Div 1 & 2; TR CU; INMETRO; KOSHA; FM; JIS and NEPSI. Please contact us for more information.
The ES-45 series magnetic proximity switches meet the requirements of IEC 61508:2010 Routes 1H & 1S with Systematic Capability (SC3) as an element/subsystem, and are suitable for use in safety-related systems performing safety functions up to and including SIL 2 with HFT=0 (1oo1) and SIL 3 with HFT=1 (1oo2).
- Body Shape
- Rectangular
- Body Material
- 316L Stainless Steel
- Contact Arrangement
- SPCO / SPDT (Form C)
- Contact Material
- Rhodium (Tungsten optional)
- Dimensions
- 67mm x 19mm x 13mm c/w fixing screws
- Max Current
- 830mA
- Connection
- PVC Cable
- Termination
- Cabled
- Hazardous Location
- Zones 0 and 20 (can also be used in 1, 2, 21 & 22)
- Temperature Class (T Rating)
- T4 / T6
- Sensing Range with Magnet
- Up to the maximum in the magnet table
- Sensing Face Pressure Rating
- 2000psi / 138 bar
- Environmental Protection
- IP 66, 67 & 68 (24hrs at 30m)/ NEMA 4X & 6P
- Safety Rating
- SIL 2 / SC3
- Actuation
- Magnetically Actuated
All of our products are also available as Ordinary Location / General Industrial.
Please select your certification and protection concept for your specific requirement from the Part Number builder below
