M-VIP-V2
M-VIP Rotary Valve Position Indication Kit
Certifications / Approvals
| Magnet Part No. | MA-1S | MA-2S | MA-3S | MA-4S | MA-7S |
|---|---|---|---|---|---|
| Sensing Range in mm (") | 6 (0.24) | 3 (0.12) | 18 (0.71) | 8 (0.31) | 10 (0.39) |
| Magnet Datasheets |  |
|
|
|
|
Multi-Voltage, Volt Free Contacts | M12 Connector
This Valve Position Switch complete with visual indication puck is designed to fit ¼ turn Namur actuators of all sizes. The housing is made from PBT Engineered resin and contains 2 x Normally Open (SPST) Contacts with a maximum switching capacity of 1.6A at 24V DC. These volt free contacts can be used for switching multiple voltages in AC or DC. It provides two independent outputs commonly used to indicate Valve Open and Valve Closed.
- Body Shape
- Rectangular
- Body Material
- Engineered Resin
- Contact Arrangement
- 2 x Normally Open (FormA)
- Contact Material
- Rhodium
- Dimensions
- 50 x 45 x 25mm c/w fixing screws
- Max Current
- 1.6A
- Connection
- PVC Cable
- Termination
- Cabled
- Certification & Approvals
- n/a
- Operating Temperature
- -20°C to +80°C / -4°F to +176°F
- Environmental Protection
- IP 66, 67 & 68 (24hrs at 30m)/ NEMA 4X & 6P
- Safety Rating
- SIL 2 / SC3
- Actuation
- Magnetically Actuated
Certification
Gas Group
Temp Rating
Compliance
SIL
All of our products are also available as Ordinary Location / General Industrial.
